SLITTING/REWINDING MACHINE FOR ABRASIVE ROLLS
Description
Machine for the slitting and rewinding of abrasive cloth and paper rolls. The purpose of this new generation machine is to provide the operator with full real-time control over the working procedure; the material is unwound and then rewound on the same side of the machine in order for the operator to be able to identify any defects on both sides of the product. The machine can be equipped with multiple accessories.
Technical data
Power supply
400V 50HZ
Rated power
8KW
Dimensions
3500X1200X2300
Weight
3000 Kg
Compressor feed available?
Yes
Cycle consumption
Test
Productiviy
High
Number of operators
1
Machine Color
RAL1013
Noise level
25 dB
Marking
CE
PPI required? YES
- SAFETY SHOES
- SHIRTS WITH ELASTIC CUFFS
- GLASSES
- GLOVES
- EARPLUGS
Accessories?
Rotary group
Multi-blade shaft
Automatic edge guides
Diameter reader
Scrap winder
Transverse cutting
